RAK7268V2/RAK7268CV2 Indoor LoRaWAN Gateway Firmware Upgrade

RAK7268V2/RAK7268CV2 Indoor LoRaWAN Gateway Firmware Upgrade

AlertALERT: This firmware (WisGateOS 2) is applicable only to V2 version of RAK7268. Non-V2 RAK7268 or RAK7258 have different firmware WisGateOS. For non-V2 RAK7258 or RAK7268 firmware update, see here: https://support.zenseio.com/portal/en/kb/articles/rak-7258-indoor-lorawan-gateway-firmware-upgrade

RAK gateways are not set up with remote firmware update capabilities. But, it's pretty easy to upgrade the firmware yourself.
  1. Find the IP address of that gateway on your network. You can log into your router to see the assigned IP address to RAK
  2. Download this firmware binary to a folder on your computer: https://downloads.rakwireless.com/LoRa/WisGateOS2/WisGateOS2_Latest_Firmware.zip
  3. Unzip this file
  4. Log into RAK gateway at the IP address. The default credentials are: username: root, password: root. It will first come up with a security screen "Your connection is not private". Click "Advanced" and "proceed"
  5. In the left pane, click Settings->Firmware, then "Choose File" - the one you unzipped earlier. IMPORTANT: select "Keep settings after updating" and press "Update"
  6. That's it.
